These forged four-way fittings feature ports in four directions and varying bore sizes; they are used for multi-branch, size-transition connections in small-bore, high-pressure piping systems. They typically employ socket-weld or threaded ends, with specific dimensions for each port clearly indicated on the drawings.
Prodotti con apparecchiature CNC avanzate e processi collaudati, le nostre flange, curve per tubi e raccordi offrono dimensioni accurate, prestazioni di tenuta stabili e installazione affidabile in applicazioni industriali impegnative.
Norme: GB/T 14383-2021; ASME B16.11-2021 per ordini di esportazione.
Structure/Ends: Reducing cross; specify the bore sizes for the four ports and the end types (socket weld or threaded).
Pressure Ratings: Class 2000, 3000, 6000 for threaded ends; Class 3000, 6000, 9000 for socket weld ends.
Fili: ASME B1.20.1 per NPT; standard specificati dal progetto per filettature domestiche di tubi di tenuta a 60°.
Materials: Carbon steel, stainless steel, or alloy steel forgings; orders must specify size, end type, pressure rating, material grade, and inspection requirements.
Ordering/Acceptance: Confirm size, Class, end type (socket weld/threaded), thread standard, mating pipe wall thickness, and material; verify socket dimensions or thread gauge fit, heat treatment, marking, and material certification.
